Description
ART MX524 Overview
System installers in need of a professional mixer with zone outputs will be impressed with the ART MX524, a 5-channel, 4-zone mic/line mixer well suited for use on permanent install applications including conference rooms, corporate boardrooms, churches, restaurants, small clubs, health clubs, and more.
This 3 RU mixer features five independent input channels with combo XLR-1/4" inputs available on channels 1 to 4, while channel 5 utilizes a stereo RCA pair. There is independent selectable +48V phantom power on inputs 1 to 4 as well. Each channel has level, bass, and treble controls on each channel and can be routed to any zone output.
- Five input channels with individual level controls using combo XLR-1/4" jacks with master level, bass, and treble controls
- Balanced Mic/Line XLR inputs for channels one thru four
- Full +48V low-noise phantom power for channels one thru four mic inputs
- Front-panel 3.5mm stereo TRS plug for headphone monitoring
- Four sets of Euroblock connectors for the Zone outputs
- Telephone paging function
- DC power back up
- Separate monitor outputs
- LED VU meter on all outputs
- Rear-mounted RCA Line inputs for additional audio inputs
- Rugged 3 RU rackmount steel chassis with built-in power supply
- Great for permanent installations
In the Box
- ART MX524 5-Channel 4-Zone Mic/Line Mixer4
- Power Cord
ART MX524 Specs
| Frequency Response | 20 Hz to 20 kHz ±2 dB |
| Maximum Input Gain | 60 dB Mic Input Main Out (XLR, Balanced) 50 dB Mic Input & REC. Out (Unbalanced) 60 dB Mic Input Mic. Out (Unbalanced) 60 dB Mic Input Mono Out (Unbalanced) |
| Impedance | Microphone Input: 1.4 Kilohms All Other Inputs 10 Kilohms or Greater Zone Outputs 120 Kilohms Monitor Speaker Output 8 Kilohms Monitor Line Output 120 Kilohms |
| Phantom Power | +48 VDC |
| Equalizer | High: 10 kHz ±10 dB Low: 100 Hz ±10 dB |
| Zone Output | +26 dB (Balanced) |
| Monitor Out | Monitor Line Output: +15 dB (Unbalanced) Monitor Speaker Output: 1 W RMS / 8 Ohms |
| Headphone Output | 0.5 W RMS / 47 Ohms |
| Connectors | Inputs (Channels 1-4): Combo XLR-1/4" / 6.35 mm (Balanced, Unbalanced) Inputs (Channel 5): Stereo RCA (Unbalanced) Outputs: Euroblock, Screw Terminals |
| Power | 110 to 120 VAC, 50/60 Hz or 24 VDC |
| Dimensions (H x W x D) | 5.1 x 19 x 7.5" / 13 x 48.3 x 19.1 cm |
| Weight | 6.6 lb / 3 kg |
| Package Weight | 12.02 lb |
| Box Dimensions (LxWxH) | 22.5 x 10.9 x 8.4" |
ART MX524 Reviews
Great Mixer
Perfect for my multizone install. Works as intended and has all the right features!
