Description
Arduino MKR WAN 1310 Evaluation Board provides a practical and cost-effective solution to add LoRa® connectivity to projects that require low power.
Features & Specs
- Microcontroller: SAMD21 Cortex-MO+ 32bit low power ARM MCU
- Radio Module: CMWX1ZZABZ
- Board Power Supply (USB/VIN): 5V
- Secure Element: ATECC508
- Supported Batteries: Rechargeable Li-Ion, or Li-Po, 1024 mAh minimum capacity
- Circuit Operating Voltage: 3.3V
- Digital I/O Pins: 8
- PWM Pins: 13 (0 .. 8, 10, 12, 18 / A3, 19 / A4)
- UART: 1
- SPI: 1
- I2C: 1
- Analog Input Pins 7 (ADC 8/10/12 bit)
- Analog Output Pins 1 (DAC 10 bit)
- External Interupts: 8 (0, 1, 4, 5, 6, 7, 8, 16 / A1, 17 / A2)
- DC Current per I/O Pin: 7 mA
- CPU Flash Memory: 256 KB (internal)
- QSPI Flash Memory: 2MByte (external)
- SRAM: 32 KB
- EEPROM: no
- Clock Speed: 32.768 kHz (RTC), 48 MHz
- LED_BUILTIN: 6
- USB: Full-Speed USB Device and embedded Host
- Carrier frequency: 433/868/915 MHz
- Working region: EU/US (confirmed)
- Length: 67.64mm
- Width: 25mm
- Weight: 32gr.
- Arduino Part #: ABX00029
Features & Specs
- Microcontroller: SAMD21 Cortex-MO+ 32bit low power ARM MCU
- Radio Module: CMWX1ZZABZ
- Board Power Supply (USB/VIN): 5V
- Secure Element: ATECC508
- Supported Batteries: Rechargeable Li-Ion, or Li-Po, 1024 mAh minimum capacity
- Circuit Operating Voltage: 3.3V
- Digital I/O Pins: 8
- PWM Pins: 13 (0 .. 8, 10, 12, 18 / A3, 19 / A4)
- UART: 1
- SPI: 1
- I2C: 1
- Analog Input Pins 7 (ADC 8/10/12 bit)
- Analog Output Pins 1 (DAC 10 bit)
- External Interupts: 8 (0, 1, 4, 5, 6, 7, 8, 16 / A1, 17 / A2)
- DC Current per I/O Pin: 7 mA
- CPU Flash Memory: 256 KB (internal)
- QSPI Flash Memory: 2MByte (external)
- SRAM: 32 KB
- EEPROM: no
- Clock Speed: 32.768 kHz (RTC), 48 MHz
- LED_BUILTIN: 6
- USB: Full-Speed USB Device and embedded Host
- Carrier frequency: 433/868/915 MHz
- Working region: EU/US (confirmed)
- Length: 67.64mm
- Width: 25mm
- Weight: 32gr.
- Arduino Part #: ABX00029
