Appsys ProAudio FLX-RAVENNA/SRC Overview

The Appsys FLX-RAVENNA/SRC Converter is a compact, high-performance solution designed to bridge RAVENNA networks with virtually any audio protocol?while maintaining exceptional audio integrity across clock domains. Featuring dual RAVENNA ports with built-in ST2110 and AES67 support, along with a powerful 64x64-channel sample rate converter, it enables seamless integration between complex systems in broadcast, live sound, and studio environments. Whether used for format conversion, system expansion, or clock-domain isolation, the FLX-RAVENNA/SRC delivers precision, flexibility, and reliability in demanding workflows.

RAVENNA to Anything, with SRC Built In

At the heart of the FLX-RAVENNA/SRC is a 64x64-channel bidirectional sample rate converter with outstanding performance, delivering >120 dB THD+N and >134 dB dynamic range. This allows for transparent conversion between different clock domains, and the SRC can be bypassed when not required. Supporting sample rates from 44.1 to 192 kHz on either side, the unit can handle complex scenarios such as 96 kHz MADI to 48 kHz Dante conversion with full 64-channel capacity in each direction.

Flexible Conversion via AUX Expansion

The integrated AUX slot enables the FLX-RAVENNA/SRC to interface with a wide range of protocols using optional AUX cards. When paired with the AUX-RAVENNA card, the unit functions as a RAVENNA-to-RAVENNA bridge with complete network and clock domain separation. Additional formats, such as Dante, can be supported with the appropriate AUX module, making the system highly adaptable to evolving infrastructure needs.

Proven RAVENNA Performance

Built on the trusted Merging/Sennheiser ZMAN module, the FLX-RAVENNA/SRC ensures stable, high-quality RAVENNA performance with support for both ST2110 and AES67 standards. Dual Ethercon-connected RAVENNA ports provide robust network connectivity for professional environments.

Scalable System Integration

For larger systems, the FlexLink port enables ultralow-latency, bidirectional transfer of up to 192 channels of audio, along with clock and power. This makes the FLX-RAVENNA/SRC an ideal expansion unit for the MVR-mkII or other Flexiverter systems. When connected to the MVR-mkII, it also enables true channel-wise routing across all available channels, including those from installed AUX cards.

Remote Control and Rock-Solid Reliability

Remote operation is simple via USB using a browser-based interface?no software installation required?or through UART command line for advanced control. A triple-redundant power supply ensures dependable operation in mission-critical applications, providing maximum uptime for live and broadcast use.

UPC: 700613618134

Items Included

Appsys ProAudio FLX-RAVENNA/SRC Converter
Limited 2-Year Manufacturer Warranty

Additional Resources

No additional resources available

Appsys ProAudio FLX-RAVENNA/SRC Specs

Key Specs

Maximum Sampling Rate	192 kHz / 16-Bit
Number of Microphone Inputs	No
Analog Audio I/O	No
Digital Audio I/O	No
Host Connection	1x USB-C
Power Requirements	AC/DC Power Adapter (Included)

General

Display	No
Built-In DSP	No
Maximum Sampling Rate	192 kHz / 16-Bit
Number of Microphone Inputs	No
Built-In Microphone	No

Signal Processing

High-Pass Filter	No
Solo/Mute	No

Connectivity

Analog Audio I/O	No
Phantom Power	No
Digital Audio I/O	No
Host Connection / USB	1x USB-C
Host Connection Protocol	USB 3.0 / 3.1/3.2 Gen 1
USB (Non-Host)	No
Sync I/O	No
Network I/O	2x etherCON/RJ45 AES67
MIDI I/O	No
Expansion Slots	1x Network I/O Slot
Other I/O	1x HDMI Expansion
Wireless	No

Digital Audio

Sample Rates	44.1 to 192 kHz
Sample Rate Conversion	No
Bit Depths	16-Bit
Sync Sources	RAVENNA

Audio Storage & Playback

Media/Memory Card Slot

Compatibility

OS Compatibility	Windows
Required Hardware	USB-C Port

Power

Power Requirements	AC/DC Power Adapter (Included)
AC/DC Power Adapter	Included
Power Consumption	18 W
