- Output: 900W / 1000 VA
- Input: 120V
- Rack/Tower Convertible
- 6 x NEMA 5-15R Outlets
- Recharge Time: 3 Hours
- RJ45 and USB Type-A Management Ports
- SmartSlot Interface
- Cold-Start/Hot-Swappable Batteries
- Audible Alarms
- LCD Status Display
Keep servers and other business-critical equipment running during a power outage with the Smart-UPS SRT 1000VA Rack/Tower (120V) from APC . This rack/tower convertible UPS has an output power capacity of up to 900W and comes equipped with six NEMA 5-15R outlets, RJ45 and USB Type-A management ports, and a SmartSlot interface for adding an optional expansion card. Also featured are cold start-capable and hot-swappable batteries, audible alarms, and an LCD status display.
General Features
- Battery Failure Notification
- Provides early-warning fault analysis on batteries enabling timely preventive maintenance.
- ECO Mode
- Operating mode that bypasses unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection.
- Graphical LCD Display
- Text and mimic diagrams that display modes of operation, system parameters and alarms.
- Rack/Tower Convertible
- Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Adaptability
- Plug-and-Play External Batteries
- Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
- Flash-Upgradeable Firmware
- Install maintenance releases of firmware remotely using FTP.
Serviceability
- Disconnected Battery Notification
- Warns when a battery is not available to provide backup power.
- Predictive Failure Notification
- Provides early-warning fault analysis ensuring proactive component replacement.
- Automatic Self-Test
- Periodic battery self-test ensures early detection of a battery that needs to be replaced.
- User-Replaceable Batteries
- Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).
- Audible Alarms
- Provides notification of changing utility power and UPS power conditions.
Availability
- Scalable Runtime
- Allows additional run time to be quickly added as needed.
- Automatic Internal Bypass
- Supplies utility power to the connected loads in the event of a UPS power overload or fault.
- Hot-Swappable Batteries
- Ensures clean, uninterrupted power to protected equipment while batteries are being replaced.
- Intelligent Battery Management
- Maximizes battery performance, life, and reliability through intelligent, precision charging.
- Temperature-Compensated Battery Charging
- Prolongs battery life by regulating the charge voltage according to battery temperature.
- Automatic Restart of Loads after UPS Shutdown
- Automatically starts up the connected equipment upon the return of utility power.
Manageability
- SmartSlot
- Customize UPS capabilities with management cards.
- InfraStruXure Manager Compatible
- Enables centralized management via the APC InfraStruXure Manager.
- Network Manageable
- Provides remote power management of the UPS over the network.
- Serial Connectivity
- Provides management of the UPS via a serial port.
- LED Status Indicators
- Quickly understand unit and power status with visual indicators.
Protection
- Safety-Agency Approved
- Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
- Resettable Circuit Breaker
- Easy recovery from overloads; no need to replace a fuse.
- Frequency and Voltage Regulation
- Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
- Input Power Factor Correction
- Minimizes installation costs by enabling the use of smaller generators and cabling.
- Power Conditioning
- Protects connected loads from surges, spikes, lightning, and other power disturbances.
- Cold-Start Capable
- Provides temporary battery power when the utility power is out.
- Generator Compatible
- Ensures clean, uninterrupted power to protected equipment when generator power is used.
UPC: 731304329985
In the Box
APC Smart-UPS SRT 1000VA Rack/Tower (120V)
Comms Cable Removable Support Feet USB Cable Limited 3-Year Warranty (Excluding Battery) Limited 2-Year Warranty (Battery)
APC SRT 1000VA Specs
| General |
| Total Outlets | 6 x NEMA 5-15R |
| Protected Outlets | 6 x NEMA 5-15R (Battery and Surge) |
| Plug Type | NEMA 5-15P |
| SmartSlot Interface | 1 |
| Communications | USB, Serial |
| Emergency Power Off (EPO) Support | Yes |
| Topology | Double Conversion |
| Power |
| Surge Energy Rating | 432 Joules |
| Maximum Current | 1000 A |
| Maximum Wattage | 900 W |
| Nominal Input Voltage | 120 VAC |
| Input Voltage Range | 50 to 150 VAC |
| Input Frequency | 50/60 Hz ± 10 Hz (Auto Sensing) |
| Nominal Output Voltage | 120 VAC |
| Output Frequency | 50/60 Hz ± 3 Hz |
| Voltage Distortion | <2% |
| Load Capacity | 1000 VA |
| Thermal Dissipation | 317 BTU/Hour |
| Crest Factor | 3:1 |
| Waveform | Sine Wave |
| Battery |
| Chemistry | Lead-Acid |
| Charging Time | 3 Hours |
| User Replaceable | Yes |
| Replacement Battery | APCRBC155 |
| Hot-Swap Support | Yes |
| Environmental |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Operating Humidity | 0 to 95% |
| Storage Temperature | -4 to 122°F / -20 to 50°C |
| Storage Humidity | 0 to 95% |
| Operating Altitude | 0 to 10,000' / 0.00 to 3048 m |
| Storage Altitude | 0 to 50,000' / 0.00 to 15,240 m |
| Noise Level | 50 dBA |
| Certifications | CSA, FCC, REACH, RoHS, UL, as per Manufacturer |
| Physical |
| Cable Length | 6' / 1.83 m |
| Dimensions (W x H x D) | 17.0 x 3.3 x 20.0" / 432.0 x 85.0 x 508.0 mm |
| Weight | 48.5 lb / 22 kg |
