| ₹ 310.22 includes GST and import duties. | |
| B2B customers can avail ₹ 47.31 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 8-338069-0 is a 10-way 1-row Female-on-board Ribbon Cable Receptacle with tin over nickel plated copper alloy contacts and tin over nickel plated solder tail. This Micro-MaTch series connector comes with red PA housing and surface mount termination. The Micro-MaTch contact helps prevent fretting corrosion, the traditional failure mode in tin-plated connections. Relative movements caused by vibrations/thermal expansion between male and female contacts are absorbed by an additional positioning spring in the female part. By preventing movements on the contact spot, a gas tight connection can make the Micro-MaTch contact spring system fretting corrosion resistant.
- UL94V-0 Flammability rating
- 1.4A Current rating
- 1000MR Insulation resistance
- 100VAC Voltage rating
- -40 to +105°C Operating temperature range
Industrial
Other details
| Brand | AMP - TE CONNECTIVITY |
| Part Number | 8-338069-0 |
| Quantity | Each (Supplied on Cut Tape) |
| Manufacturer Catalogue EN |  |
| 3D Product Image EN | |
| Manufacturer Product Page EN | |
| Drawing EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 304.02 |
| 3-5 | ₹ 300.91 |
| 5-10 | ₹ 294.71 |
| 10+ | ₹ 288.5 |
Bulk discount will be automatically applied during checkout based on quantity.
