Description
The 280372-2 is a 6-way 1-row Shrouded Header with thermoplastic housing and tin-plated phosphor bronze contacts, 2.54mm pitch spacing and through hole termination. This shrouded header is suitable for use with printed circuit board.
- Black housing
- UL94V-0 Flammability rating
- 15µinch Plating thickness of contact mating area
- Operating temperature range -40°C to 80°C
- Contact resistance of 15mohm
- Insulation resistance of 5000Mohm
- Tin and gold plated contacts available
- Features 0.63mm posts with mating receptacles
Industrial
Other details
| Brand | AMP - TE CONNECTIVITY |
| Part Number | 280372-2 |
| Quantity | Each |
| 3D Product Image EN |  |
| Drawing EN | |
| Product Change Notice EN | |
