| ₹ 205.24 includes GST and import duties. | |
| B2B customers can avail ₹ 31.3 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The 215307-6 is a 12-way 2-row Vertical Board-to-board Receptacle with gold-plated phosphor bronze contacts and tin-plated solder tail. This AMPMODU HV-100 series internal equipment connector comes with black polyester-GF housing and through hole solder termination, can be used with header assembly.
- UL94V-0 Flammability rating
- 3A contact current rating
- Mates with 0.63" square/round MODU posts
- Retention solder tails
- Top entry
- Green housing
Industrial
Other details
| Brand | AMP - TE CONNECTIVITY |
| Part Number | 215307-6 |
| Quantity | Each |
| 3D Product Image EN |  |
| Drawing EN | |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 201.14 |
| 3-5 | ₹ 199.08 |
| 5-10 | ₹ 194.98 |
| 10+ | ₹ 190.87 |
Bulk discount will be automatically applied during checkout based on quantity.
