Description
The 1-5745967-4 is a 25-way 2-row front metal-shell D-sub Receptacle with gold-plated phosphor bronze contacts and fixed zinc female screwlocks. The Amplimite HD-20 series straight posted receptacle comes with black polyester housing, tin-plated carbon steel shell, brass inserts and tin-plated solder tail. All receptacles are preloaded with size 20 DF posted socket contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308.
- UL94V-0 Flammability rating
- Vertical PCB mounting orientation
- Shielded
Industrial, Computers & Computer Peripherals
Other details
| Brand | AMP - TE CONNECTIVITY |
| Part Number | 1-5745967-4 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| One Page Summary EN | |
| Drawing EN | |
| Manufacturer Catalogue EN | |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1008.65 |
| 3-5 | ₹ 998.35 |
| 5-10 | ₹ 977.77 |
| 10+ | ₹ 957.18 |
Bulk discount will be automatically applied during checkout based on quantity.
