Description
American DJ UBL12HB Overview
Craft captivating displays on walls, floors, and ceilings with the American DJ UBL12HB, a 42" versatile LED linear fixture with twelve 20W, 6-in-1 HEX LEDs (RGBAL+UV) well suited for uplighting, downlighting, stage washing, and dance floor illumination. The inclusion of the lime LED chip allows for a high CRI of >90, which ensures the fixture�s output will render colors accurately when used to illuminate scenery, décor, and people.
The LEDs are arranged in independently controllable pairs or groups of three, allowing for smooth color mixing, while creating of a wide variety of hues and shades. Additionally, the fixtures can also be used to generate white light output with color temperature variable between 2300 and 9900K. For even more versatility, the UV element allows the creation of a "blacklight" effect, causing white and neon colored décor and clothing to glow when used alone. The UBL12H comes complete with an indoor locking power cord, UC-IR24 remote, and a 20° diffusion filter.
- Ultrabright, 42" indoor linear bar with 12 x 20W ultrabright HEX (RGBAL + UV 6-in-1) LEDs
- Long-life LEDs (rated at approximately 50,000 hours)
- Linear color temperature control (2300 to 9900K)
- Smooth RGBAL+UV color mixing
- OLED display with 4-buttons
- 7 DMX channel modes: 6, 11, 13, 16, 36, 43, and 46 channels
- RDM Compatible
- 6 groups of two, RGBAL+UV LED pixels controllable via DMX in 36, 43, and 46 channel modes
- 5 operational modes: Auto Run, Program Mode, Sound Trigger, RGBAL+UV Manual, and DMX-512 Mode
- LED refresh rate: 1.9 kHz
- 64 built-in color macros
- 6 selectable Dim modes (Standard, Stage, TV, Architectural, Theatre, and Stage 2)
- 4 selectable Dim curves (Square, Linear, Inv. Square, and S. Curve)
- Built-in microphone for sound trigger
- Pulse and strobe effect
- Electronic dimming: 0-100
- Built-in horizontal magnetic alignment feature
Items Included
- American DJ UBL12HB RGBAL+UV Linear Light Bar with Diffusion Filter (12 LEDs)
- AC Cable
- 20° Diffusion Filter
- UC-IR24 Remote Control
- 2 x Mounting Bracket
- Limited 2-Year Manufacturer Warranty
Additional Resources
No additional resources available
American DJ UBL12HB Specs
| Fixture Type |
Linear/Bar Light
|
| Light Source |
12x Color/UV LED - 20 W
|
| Colors |
Amber, Blue, Green, Lime, Red, Ultraviolet
|
| Pixel Configuration |
6x Zone
|
| Beam Angle |
17°
20° (with Filter) |
| Control Protocols |
DMX512, RDM, Aria X2
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Battery Type |
22.2 V Lithium-Ion
|
| Mounting |
Floor Base, Mounting Bracket
|
| Fixture Type |
Linear/Bar Light
|
| Light Source |
12x Color/UV LED - 20 W
|
| Expected Lamp Life |
50,000 Hours
|
| Colors |
Amber, Blue, Green, Lime, Red, Ultraviolet
|
| Pixel Configuration |
6x Zone
|
| Color Temperature |
2300 to 9990K
|
| Beam Angle |
17°
20° (with Filter) |
| Shutter / Strobe |
Electronic
|
| Iris |
No
|
| Focus |
Manual
|
| Zoom Adjustment |
No
|
| Dimming |
Electronic, 0 to 100% with 6 Dimmer Modes
|
| Operating Modes |
Automatic, DMX, Sound-Active, Static Color
|
| Macros / Programs |
64x Color Macro
|
| Effects |
Strobe
Pulse |
| Gobos |
No
|
| Color Accuracy Index |
CRI: > 90
|
| Refresh Rate |
1.9 kHz
|
| Control Protocols |
DMX512, RDM, Aria X2
|
| DMX Channel Modes |
7 Mode(s):
6 / 11 / 13 / 16 / 36 / 43 / 46-Channel |
| Display / Controls |
OLED / 4-Button
|
| Remote Control |
IR Remote (with Included Equipment)
|
| Mobile App Compatible |
No
|
| Inputs/Outputs |
1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output |
| Wireless |
IR
|
| Wireless Range |
32.8' / 10 m
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1x powerCON
Output: 1x powerCON |
| Fuse |
No
|
| Power / Current Consumption |
61 W
|
| Power Linking |
17 Units at 120 VAC
32 Units at 230 VAC |
| Battery Type |
22.2 V Lithium-Ion
|
| Battery Capacity |
7000 mAh
|
| Approximate Battery Life |
Up to 20 Hours
|
| Battery Charging Time |
5 Hours
|
| Environmental Resistance |
Dust-Resistant (IP20)
|
| Mounting |
Floor Base, Mounting Bracket
|
| Included Accessories |
1x Power Cable
1x Filter |
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Certifications |
CE, cETLus, FCC
|
| Dimensions |
42.6 x 4.2 x 2.96" / 1082.04 x 106.7 x 75.18 mm
|
| Weight |
7.5 lb / 3.4 kg
|
