Description
American DJ Focus Spot Z7 Overview
ADJ Focus Spot 7Z Features Video
ADJ Lighting Focus Spot 7Z QC Line Short
ADJ Lighting Focus Spot 7Z Features Short
ADJ Lighting Focus Spot 7Z Lightshow
ADJ Focus Spot 7Z CMY Color Mixing, Variable CTO & Color Wheel Features
ADJ Focus Spot 7Z Motorized Iris, Zoom & Focus Short
Lighting designers in search of a fixture capable of producing beam, spot, and wash effects should look no further than the American DJ Focus Spot 7Z, a powerful and feature-packed moving head spot luminaire well suited for film and TV, event production, and rental houses as well as permanent installations in concert halls, theaters, nightclubs, and churches.
The Focus Spot 7Z is powered by a 420W white LED engine and features variable CMY and CTO color mixing with a color wheel that features 7 dichroic slots. The fixture features two independent GOBO wheels, each of which incorporate seven slots for interchangeable, indexed-rotating patterns. In addition, it also incorporates an animation wheel with indexed rotation as well as two separate rotating prisms (4-facet circular and 6-facet linear). Motorized zoom (6 ~ 48°), focus and iris are integrated into the optical system as are two separate frost filters. The Focus Spot 7Z includes two Omega brackets and a powerCON power cable.
- 420W white LED engine (20,000-hour average LED life)
- 20,000 total lumens
- 8000K, >73 CRI (without CRI filter)
- 7700K >85 CRI (with CRI filter)
- 56,513 lux at 16.4� (6° beam)
- 1585 lux at 16.4� (48° beam)
- 4-facet circular and 6-facet linear rotating prisms
- 2 frost filters (light & heavy)
- Animation wheel (rotatable and indexable)
- Motorized zoom (6 to 48°)
- Motorized focus
- Motorized iris
- Electronic dimming & strobe (1 to 20 Hz)
- Full CMY color mixing
- Variable CTO (2700 to 8000K)
- Colors wheel with 7 dichroic slots (includes high CRI and CTB filters)
- CMY and color wheel preset macros
- Two gobo wheels: 7 interchangeable rotating-indexing glass gobos each
- DMX channel modes (30 / 34 / 45)
- DMX512, ArtNet, and sACN protocols
- Aria XT wireless DMX
- RDM (remote device management) compliant
- 6-button touch-control panel
- Full color 180° reversible LCD menu display
- 8- or 16-bit resolution adjustable movement
- 5-pin XLR DMX in/out
- Locking in/out power connections
- With wired digital communication network
- Pan: 540°
- Tilt: 270°
- Pan and tilt locks
UPC: 810087371401
In the Box
- American DJ Focus Spot 7Z 7-Color LED Moving Head
- 2 x Omega Brackets
- powerCON Power Cord
- Limited 2-Year Manufacturer Warranty
American DJ Focus Spot Z7 Specs
Key Specs
| Fixture Type |
Moving Head
|
| Light Source |
1x White LED - 420 W
|
| Colors |
Cool White, Unspecified Colors (Spot)
CTO (Color Temperature Orange), Ultraviolet (Included Gels/Filters) Blue, CTB (Color Temperature Blue), Dark Blue, Green, HCRI (High CRI), Orange, Red |
| Beam Angle |
6 to 48°
|
| Control Protocols |
DMX512, Art-Net, sACN
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
524 W (Max)
|
| Mounting |
Floor Base, Omega Bracket
|
Light
| Fixture Type |
Moving Head
|
| Light Source |
1x White LED - 420 W
|
| Expected Lamp Life |
20,000 Hours
|
| Colors |
Cool White, Unspecified Colors (Spot)
CTO (Color Temperature Orange), Ultraviolet (Included Gels/Filters) Blue, CTB (Color Temperature Blue), Dark Blue, Green, HCRI (High CRI), Orange, Red |
| Photometrics |
6°:
5250 fc / 56,513 Lux at 16.4' / 5 m 48°: 147 fc / 1585 Lux at 16.4' / 5 m |
| Color Temperature |
7700 to 8000K
|
| Lumen Output |
20,000 Lumens
|
| Beam Angle |
6 to 48°
|
| Shutter / Strobe |
Electronic
|
| Iris |
Yes, Mechanical
|
| Focus |
Motorized
|
| Zoom Adjustment |
Motorized, 6 to 48°
|
| Dimming |
Electronic, 0 to 100% with 6 Dimmer Modes
|
| Prism |
4-Facet Circular (Rotating)
6-Facet Linear (Rotating) |
Performance
| Operating Modes |
Automatic, DMX, Program, Standalone
|
| Macros / Programs |
7x Auto-Program
27x Color Macro 24x Gobo Macro |
| Effects |
Frost Filter
Strobe (Variable Speed) Gobo Shake |
| Strobe Rate |
1 to 20 Hz
|
| Gobos |
6x Removable Glass Gobo
1x Spot/Open 6x Removable Glass Gobo 1x Spot/Open 1x Animation Wheel |
| Gobo Size |
Outer Diameter: 0.9" / 23 mm
Max Image Size: 0.7" / 19 mm Max Thickness: 0" / 1.1 mm |
| Refresh Rate |
900 Hz to 25,000 Hz
|
Movement
| Tilt Ranges |
270°
|
| Pan Ranges |
540°
|
| Pan/Tilt Inversion |
Yes
|
| Movement Resolution |
8-Bit
|
Control
| Control Protocols |
DMX512, Art-Net, sACN
|
| DMX Channel Modes |
3 Mode(s):
30 / 34 / 45-Channel |
| Display / Controls |
LCD / 6-Button
|
| Remote Control |
No
|
| Mobile App Compatible |
No
|
Connectivity
| Inputs/Outputs |
1 x RJ45 Network Input
1 x RJ45 Network Output 1 x XLR 5-Pin DMX Input 1 x XLR 5-Pin DMX Output |
Power
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1x powerCON
Output: 1x powerCON |
| Power / Current Consumption |
524 W (Max)
|
| Power Linking |
No
|
Environmental
| Environmental Protection |
No
|
Physical
| Mounting |
Floor Base, Omega Bracket
|
| Included Accessories |
1x Power Cable
|
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Cooling |
Fan (Variable Speed)
|
| Dimensions |
24.81 x 14.7 x 9.2" / 63.02 x 37.3 x 23.4 cm
|
| Weight |
51.7 lb / 23.5 kg
|
