Description
American DJ Encore LP5IP Overview
Lighting designers and event producers looking for a high-quality PAR fixture capable of withstanding the elements will be impressed with the American DJ Encore LP5IP, a heavy-duty IP65 outdoor-rated LED PAR with a 10° beam angle, well suited for professional indoor and outdoor events. The instrument features five 20W quad (4-in-1 RGBL) LEDs with 64 built-in color macros and includes five dimming curves plus smooth 0 to 100% electronic dimming.
There are four operational modes, including Static Color, RGBL Dimmer, Program, and DMX Controlled, which offers six DMX channel modes. The 4-button LED display menu allows for easy navigation and programming. The instrument includes 5-pin DMX inputs and outputs, as well as a powerCON input and pass-through. The dual-scissor yoke bracket allows fixtures to be hung or set on the ground. The Encore LP5IP ships with a powerCON power cable and a 25° frost filter.
- Linear color temperature control (2700 to 7000K)
- Preset color temperatures (2700, 3200, 4000, 5600, and 6500K)
- 16-bit fine color control (red, green, blue, and lime)
- 64 built-in color macros
- 4-button DMX digital display on the rear panel
- 4 operational modes: Static Color, RGBL Dimmer, Program, and DMX Controlled
- Supports RDM (Remote Device Management)
- Wired digital communication network
- 6 selectable dimming modes (Standard, Stage, TV, Architectural, Theatre, and Stage 2)
- 4 selectable dim curves (Linear, Square Inv., Square, S-Curve)
- Adjustable refresh rate (14 presets from 900 to 25,000 Hz)
- Flicker-free operation (no flickering on camera)
- LED pulse and strobe effect
- Electronic dimming: 0 to 100%
- 6 DMX modes: 4, 7, 8, 10, 13, and 16-channel
- Quiet Fan mode
- IP65 rated: Ingress protection against liquid, snow, dust, and sand
- All-metal construction
- IP-rated rubber covers protect in/out locking power connectors and IP-rated 5-pin sockets
- Locking outdoor in/out power connectors
- Data linkable via 5-pin XLR DMX connections
- Scissor yoke and safety eye
In the Box
- American DJ Encore LP5IP Heavy-Duty IP65 Outdoor-Rated LED PAR (RGBL)
- powerCON Power Cable
- Frost Filter (25°)
- Limited 2-Year Manufacturer Warranty
American DJ Encore LP5IP Specs
| Fixture Type |
PAR
|
| Light Source |
5 x Color LED - 20 W
|
| Colors |
Red, Green, Blue, Lime
|
| Beam Angle |
9.7°
|
| Control Protocols |
DMX512
|
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| Power / Current Consumption |
32 W
|
| Environmental Protection |
Advertised as Weather Resistant
*Manufacturer Testing: IP65 |
| Mounting |
Dual/Scissor Yoke
|
| Fixture Type |
PAR
|
| Light Source |
5 x Color LED - 20 W
|
| Colors |
Red, Green, Blue, Lime
|
| Photometrics |
202 fc / 2179 Lux at 9.8' / 3 m
73 fc / 785 Lux at 16.4' / 5 m |
| Color Temperature |
2700 to 7000K
|
| Lumen Output |
771 Lumens
|
| Beam Angle |
9.7°
|
| Field Angle |
18.8°
|
| Shutter / Strobe |
Electronic
|
| Iris |
No
|
| Zoom Adjustment |
No
|
| Dimming |
Electronic, 0 to 100%
|
| Operating Modes |
Color Dimmer, DMX, Program, Static Color
|
| Macros / Programs |
64 x Color Macro
|
| Effects |
Strobe
Pulse |
| Gobos |
No
|
| Color Accuracy Index |
CRI: 67 to 83
|
| Refresh Rate |
900 Hz to 25,000 Hz
|
| Control Protocols |
DMX512
|
| DMX Channel Modes |
6 Mode(s):
4 / 7 / 8 / 10 / 13 / 16-Channel |
| Display / Controls |
LCD / 4-Button
|
| Remote Control |
No
|
| Mobile App Compatible |
No
*As of November, 2022: Check with manufacturer for the most up-to-date compatibility |
| Inputs/Outputs |
1 x XLR 5-Pin DMX Input
1 x XLR 5-Pin DMX Output |
| AC Input Power |
100 to 240 VAC, 50/60 Hz
|
| AC Power Connector |
Input: 1 x powerCON TRUE1
Output: 1 x powerCON TRUE1 |
| Power / Current Consumption |
32 W
|
| Power Linking |
21 Units at 110 VAC
44 Units at 240 VAC |
| Environmental Protection |
Advertised as Weather Resistant
*Manufacturer Testing: IP65 |
| Mounting |
Dual/Scissor Yoke
|
| Included Accessories |
1 x Filter
1 x Power Cable |
| Duty Cycle |
No
|
| Exterior Color |
Black
|
| Cooling |
Fan
|
| Certifications |
cETLus
|
| Dimensions |
10.1 x 8.2 x 5.9" / 25.7 x 20.8 x 15 cm
|
| Weight |
5.3 lb / 2.4 kg
|
