- CPR: Not Yet Qualified
- 5.5lbs Maximum pull tension
- 0.06µH/ft Nominal inductance
Product details
| Jacket Material:
PVC
|
| Jacket Colour:
Black
|
| Wire Gauge:
22AWG
|
| Conductor Area CSA:
0.357mm²
|
| Reel Length (Imperial):
1000ft
|
| Reel Length (Metric):
304.8m
|
| Operating Temperature Max:
105°C
|
| No. of Max Strands x Strand Size:
7 x 0.255mm
|
| Voltage Rating:
300V
|
| Conductor Material:
Tinned Copper
|
| External Diameter:
1.575mm
|
| Approval Specification:
MIL-DTL-16878/2 (Type C), CSA REW XLPVC FT1, UL 1430
|
| Product Range:
-
|
Other details
| Brand |
ALPHA WIRE |
| Part Number |
7131 BK001 |
| Quantity |
Reel of 1 |
| Technical Data Sheet EN |
 |
