- CPR: Not Yet Qualified
- Excellent flame resistance
- 0.88lbs Maximum pull tension
- 0.09µH/ft Nominal inductance
Product details
| Jacket Material:
PVC
|
| Jacket Colour:
Blue
|
| Wire Gauge:
30AWG
|
| Conductor Area CSA:
0.057mm²
|
| Reel Length (Imperial):
100ft
|
| Reel Length (Metric):
30.5m
|
| Operating Temperature Max:
105°C
|
| No. of Max Strands x Strand Size:
7 x 38AWG
|
| Voltage Rating:
300V
|
| Conductor Material:
Tinned Copper
|
| External Diameter:
1.118mm
|
| Approval Specification:
CSA AWM I A/B FT1, CSA TR-64 FT1, UL 1007,UL 1581,UL 1569, UL VW-1
|
| Product Range:
-
|
Other details
| Brand |
ALPHA WIRE |
| Part Number |
3047 BL005 |
| Quantity |
Reel of 1 |
| Technical Data Sheet EN |
 |
