Description
This is a TIME DELAY RELAY, DPDT, 50S, 240VAC product from AGASTAT - TE CONNECTIVITY with the model number 7022AD
Product details
| Contact Voltage VDC | - |
| Time Min | 5s |
| Time Max | 50s |
| Product Range | 7000 Series |
| Contact Configuration | DPDT |
| Contact Current | 10A |
| Relay Mounting | Panel |
| Contact Voltage VAC | 240VAC |
| Relay Terminals | Quick Connect |
| Nom Input Voltage | 120VAC |
| Timing Adjustment | Knob |
| Approvals & Standards | CSA, UL |
Other details
| Brand | AGASTAT - TE CONNECTIVITY |
| Part Number | 7022AD |
| Quantity | Each |
| Technical Data Sheet EN |  |
