This is a Surface Mount Power Inductor, AEC-Q200, ASPIAIG-H8540 Series, 2.2 µH, 6.1 A, 14 A, Shielded, 12 ohm product from ABRACON with the model number ASPIAIG-H8540-2R2M-T
Product details
| Product Range |
ASPIAIG-H8540 Series |
| Inductance |
2.2µH |
| RMS Current (Irms) |
6.1A |
| Saturation Current (Isat) |
14A |
| Inductor Construction |
Shielded |
| DC Resistance Max |
12ohm |
| Power Inductor Case |
8.8mm x 8.5mm x 4mm |
| Inductance Tolerance |
± 20% |
| Packaging |
Cut Tape |
Other details
| Brand |
ABRACON |
| Part Number |
ASPIAIG-H8540-2R2M-T |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
