1SVR405613R8300 is a pluggable interface miniature relay, which is to be plugged into a suitable ABB CR-M socket. Plugged into a socket, the combination of relay and socket may be seamlessly snap-on mounted onto a DIN rail. This relay operates with a 125VDC rated control supply voltage and has a 4 c/o (SPDT) output with contacts rated at 250V / 6A, enabling the possibility of switching multiple circuits with a single input signal. The relay has an integrated test button which is used for the manual actuation of the relay by locking its output contacts. The test button facilitates easy testing and commissioning. The relay also has an integrated LED, which provides a visual indication of the energization of the relay coil.
- Pluggable miniature interface relay CR-M function, relay with built in LED
- 125VDC rated control supply voltage, 250VAC rated operational voltage
- 250V / 6A output signal, flat-pin connections
- 250V rated insulation voltage, IP40 degree of protection
- 1 mounting position
- CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61810-1, UL 508 standards
- 21.2mm product net width, 35.6mm product net height, 27.5mm product net depth / length
- Operation ambient air temperature range from -40 to +70°C
Product details
| Contact Configuration:
4PDT
|
| Coil Voltage:
125VDC
|
| Contact Current:
6A
|
| Product Range:
CR-M Series
|
| Relay Mounting:
Socket
|
| Coil Type:
DC
|
| Contact Voltage VAC:
250V
|
| Relay Terminals:
Plug In
|
| Contact Voltage VDC:
-
|
| Contact Material:
Silver Nickel
|
| Coil Resistance:
16kohm
|
Other details
| Brand |
ABB |
| Part Number |
1SVR405613R8300 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
