1SNA645521R2000 is a spring optocoupler OBRIC0100-24VDC rated control supply voltage/ solid-state output rated 4.5-58VDC, 1mA up to 100mA with integrated LED.
- Boxed optocoupler R600 function, solid-state output
- 24VDC rated control supply voltage, 4.5 to 58VDC / 1mA to 100mA output signal range
- Spring terminals type
- CAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 60947-5-1, UL 508 standards
- 6mm product net width, 67.5mm product net height, 75mm product net depth / length
Product details
| No. of Channels:
1 Channel
|
| Optocoupler Case Style:
Module
|
| No. of Pins:
-
|
| Forward Current If Max:
100mA
|
| Isolation Voltage:
-
|
| CTR Min:
-
|
| Collector Emitter Voltage V(br)ceo:
58VDC
|
| Product Range:
-
|
Other details
| Brand |
ABB |
| Part Number |
1SNA645521R2000 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
