8Sinn 8-GH5 C V2+8-THSV2 Overview
-
1Description
-
28Sinn Cage V2 for Panasonic GH5/GH5 II/GH5S
-
38Sinn Scorpio Top Handle
-
48Sinn ARRI Rosette 28mm Mount
The Cage V2 with Top Handle Scorpio for Panasonic GH5/GH5 II/GH5S from 8Sinn is a comprehensive rig system for the Panasonic GH5, the GH5 II, and the GH5S that bundles a formfitting cage with a Top Handle Scorpio. The aluminum combo kit offers users a very versatile and portable solution that maintains a compact design while providing a more flexible handheld experience.
8Sinn Cage V2 for Panasonic GH5/GH5 II/GH5S
This upgraded Cage V2 from 8Sinn is custom-fit to your Panasonic Lumix GH5, GH5 II, or GH5S mirrorless camera for expanded mounting capabilities while maintaining access to the buttons and controls of the camera. Multiple 1/4"-20 and 3/8"-16 ARRI-style threads allow you to mount accessories like articulating arms and secondary monitors onto the cage.
The top of the cage has M4 threads for mounting a compatible top handle extension adapter, as well as a cold shoe mount for integration of a wireless transmitter or shotgun microphone. A strap attachment slot allows you to insert a carrying strap of your choice for increased portability.
Panasonic Lumix GH5, GH5 II, and GH5S
The Scorpio Top Handle from 8Sinn is made of CNC aluminum. The handle features 1/4"-20 and 3/8"-16 mounting holes, four cold shoes, and a 15mm rod mount.
8Sinn ARRI Rosette 28mm Mount
The 8Sinn ARRI Rosette 28mm Mount is a standard-size ARRI rosette mount with an M6 thread in the center for attaching compatible handgrips and other accessories. It can be secured to camera cages and other supports that have two 1/4"-20 mounting threads. It secures with two included 1/4"-20 screws, and it features wide 1/4"-20 pass-through slots so you can set the screws at the required spacing to match the accessory you're attaching to.
In the Box
- 8Sinn Cage V2 for Panasonic GH5/GH5 II/GH5S
- Limited 1-Year Manufacturer Warranty
- 8Sinn Scorpio Top Handle
- Limited 1-Year Manufacturer Warranty
- 8Sinn ARRI Rosette 28mm Mount
- 2 x 1/4"-20 Mounting Screw
- Limited 1-Year Manufacturer Warranty
Table of Contents
- Description
- 8Sinn Cage V2 for Panasonic GH5/GH5 II/GH5S
- 8Sinn Scorpio Top Handle
- 8Sinn ARRI Rosette 28mm Mount
8Sinn Cage V2 for Panasonic GH5/GH5 II/GH5S Specs
Mounting
| Battery Plate Type |
None |
| Accessory Mounting |
Multiple x 1/4"-20 Female Thread, Multiple x 3/8"-16 Female Thread, Multiple x M4 Female Thread |
| Shoe Mounting |
1 x Cold Shoe |
| Rosettes |
None |
General
| Support Type |
Cage |
| Grip Type |
Grip Required (Not Included) |
| Camera Compatibility |
Panasonic DC-GH5, Panasonic DC-GH5 Mark II, Panasonic DC-GH5S |
| Dimensions |
6 x 4.2 x 2.5" / 153 x 106 x 64 mm |
| Weight |
6.7 oz / 190 g |
8Sinn Scorpio Top Handle Specs
Mounting
| Accessory Mounting |
Multiple x 1/4"-20 Thread
Multiple x 3/8"-16 Thread |
General
| Materials |
Aluminum |
| Dimensions |
5.7 x 2.8 x 1" / 14.5 x 7.1 x 2.5 cm |
| Weight |
7.7 oz / 218 g |
Packaging Info
| Package Weight |
0.8 lb |
| Box Dimensions (LxWxH) |
9.2 x 6 x 3.2" |
8Sinn ARRI Rosette 28mm Mount Specs
General
| Material of Construction |
Aluminum |
| Center Thread |
M6 |
| Rosette Diameter |
28 mm Standard |
| Dimensions |
1.7 x 0.3 x 1.1" / 44 x 8 x 28 mm |
| Weight |
0.67 oz / 19 g |
Packaging Info
| Package Weight |
0.01 lb |
| Box Dimensions (LxWxH) |
4.1 x 1.4 x 0.9" |
