8Sinn 8-FX3 C+8-THP Overview
The 8Sinn Cage for Sony FX3 + Top Handle Pro combines a formfitting protective cage with an adjustable top handle that offers side-to-side and front-to-back balance adjustments. The Top Handle Pro mounts on top of the cage via an included NATO rail you mount on top of the cage. This provides a solid connection between handle and cage and allows you to adjust the balance side to side as well as slide the handle off when not using it.
The cage features numerous 1/4"-20 threaded accessory mounting holes, and it protects your camera from the stress of attaching accessories while leaving you access to your camera's controls and functions. The top handle grip is a shaft you can easily slide forward and back as well as remove and reverse from the NATO rail mount. This allows you to adjust the balance of your camera front and back when carrying it by the top handle. The top handle grip has cold shoes on top as well as the front; the back of the grip has an opening for a 15mm rod. The top handle grip has numerous 1/4"-20 and 3/8"-16 threaded mounting holes.
Note:
Please note that the cage is not compatible with the Metabones Canon EF/EF-S Lens to Sony E Mount T CINE Smart Adapter (Fifth Generation)
8Sinn Cage for Sony FX3
Protecting your camera from the rigors of production while providing multiple accessory mounting points is the purpose of the 8Sinn Cage for Sony FX3. Your camera mounts onto this formfitting cage with a 1/4"-20 slot and is secured both at the baseplate and with a screw in the side. The cage allows access to the camera's controls and hot shoe, and the base features a multitude of 1/4"-20 mounting holes as well as a single 3/8"-16 for attaching to a tripod.
Multiple 1/4"-20 threaded holes distributed along the sides and top of the cage; it also sports two 3/8"-16 threaded hole with ARRI-style anti-twist divots on its top as well as a single 3/8"-16 threaded hole with ARRI-style anti-twist divots on the left side. Strap slots allow you to attach a camera strap if you wish, and threaded mounting holes in front of the cage enable mounting optional lens adapters. The cage is compatible with the FX3 original XLR handle.
Note:
Please note that the cage is not compatible with the Metabones Canon EF/EF-S Lens to Sony E Mount T CINE Smart Adapter (Fifth Generation)
8Sinn Top Handle Pro with NATO Rail (2.4")
The 8Sinn Pro Top Handle mounts easily on your camera cage using the included 2.4" NATO rail. The NATO rail mount makes it easy to attach and remove the handle and slides to help balance your camera. It features a single 15mm rod bracket, two cold shoe mounts, and multiple 1/4"-20 and 3/8"-16 accessory threads.
In the Box
- 8Sinn Cage for Sony FX3
- 8Sinn Top Handle Pro with NATO Rail (2.4")
- NATO Rail (2.4")
- 2 x 1/4"-20 Screw
- Limited 1-Year Warranty
8Sinn Cage for Sony FX3 Specs
Mounting
| Battery Plate Type |
None |
| Accessory Mounting |
Cage, Top: 12 x 1/4"-20 Thread, 2 x ARRI Anti-Twist 3/8"-16 Thread
Cage, Sides: 16 x 1/4"-20 Thread, 1 x ARRI Anti-Twist 3/8"-16 Thread |
| Camera Mounting |
1/4"-20 Screw |
| Tripod Mounting |
Cage: 1/4"-20 Thread, 3/8"-16 Thread |
| Shoe Mounting |
None |
| Rosettes |
None |
General
| Support Type |
Cage |
| Grip Type |
None |
| Camera Compatibility |
Sony FX3 |
| Materials |
Aluminum |
| Dimensions |
5.8 x 3.7 x 2.4" / 147 x 94 x 62 mm |
| Weight |
7.8 oz / 220 g |
Packaging Info
| Package Weight |
0.825 lb |
| Box Dimensions (LxWxH) |
9.2 x 5.9 x 3.1" |
8Sinn Top Handle Pro with NATO Rail (2.4") Specs
| Grip Type |
Topside Handle with Cheeseplate-Style Handle |
| Rotation |
No |
| Built-In Controls |
None |
Mounting
| Attachment Method |
Attaches via Rail |
| Rod Standard |
15 mm Single Rod |
| Rod Ports |
1 x 15 mm Rod Port |
| Accessory Mounting |
Multiple x 1/4"-20 Thread
Multiple x 3/8"-16 Thread |
| Shoe Mounting |
2 x Built-In Cold Shoe Slot |
| Rosettes |
None |
| Rail Mounting |
1 x NATO Rail Clamp
1 x NATO Rail That Attaches via 2 x Included 1/4"-20 Screw |
General
| Materials |
Aluminum |
| Dimensions |
6.2 x 2.7 x 2.3" / 158 x 69 x 59 mm |
| Weight |
5.1 oz / 145 g |
Packaging Info
| Package Weight |
0.7 lb |
| Box Dimensions (LxWxH) |
9.2 x 5.7 x 3.1" |
