Description
The 10150-3000PE from 3M is a mini D ribbon (MDR) shielded wire mount plug connector with 50 positions. This connector accepts a wide variety of discrete wire (24AWG to 30AWG) cable construction.
- Wiper on wiper contact for reliable repetitive plugging
- Solder cup termination requires no special tooling
- UL94 V-0 rated black colour glass reinforced polyester insulation
- Copper alloy contacts with 80�inch (2�m) nickel under plating
- 20�inch (0.5�m) minimum gold wiping interface
- Gold flash over nickel solder tail plating (RIA E1 & C1 apply)
- Gold flash solder cup and steel shroud with nickel plating
- Current rating of 1A
- High temperature rating from -55�C to 105�C
- Withstand voltage of 500Vrms for 1 minute
Applications
Industrial
Product details
| No. of Contacts | 50Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Plug |
| Product Range | 101 Series |
| Contact Material | Copper Alloy |
| Contact Termination Type | Solder |
| Connector Mounting | Cable Mount |
Other details
| Brand | 3M |
| Part Number | 10150-3000PE |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
