3 Legged Thing AirHed Cine Overview
The compact, lightweight AirHed Cine Video Head with Arca-Type Plate from 3 Legged Thing in a jet-black Darkness color weighs only 1.25 lb and can support cameras and rigs weighing up to 22 lb. The head has a fixed fluid drag system and fixed counterbalance, with 165° of tilt and 360° of pan rotation for smooth camera moves. There are separate pan and tilt lock levers for locked-off shots, and the pan axis is indexed for repeatability.
The included Arca-type plate features rubber padding to protect your camera and prevent twisting, as well as a 1/4"-20 camera mounting screw. The AirHed Cine can also accept any Arca-type compatible quick release plate, making it easy to find spares or replacements. The two integrated bubble levels aid in setting up level horizons. The adjustable pan handle can be mounted onto either side of the video head using the built-in rosettes, and there is a 1/4"-20 accessory thread to mount an additional accessory. The AirHed Cine can be mounted on ball adapters, tripods, and other camera supports via the 3/8"-16 threaded female receiver on the flat base.
Smooth, adjustable tilt function with friction control
Tilt can be controlled directly or with supplied panning arm
Arca-type quick release plate with stainless steel 1/4"-20 mounting screw
Two built-in bubble levels for accurate leveling
Magnesium alloy construction
360° panning base with lock
Panning arm can be mounted on either side for right- or left-handed operation
Knurled clamp knob for improved grip and leverage
1/4"-20 screw thread for attachment of accessories
In the Box
- 3 Legged Thing AirHed Cine Video Head with Arca-Type Plate (Darkness)
- Arca-Type Quick Release Plate
- Pan Bar
- Carry Bag
- Limited 5-Year Manufacturer Warranty
3 Legged Thing AirHed Cine Specs
Camera Plate
| Camera Plate Features |
Quick Release |
| Camera Plate Type |
Arca-type |
| Camera Mounting Screw |
1 x 1/4"-20 Male |
| Safety Lock |
Yes |
Head
| Base Mount |
3/8"-16 Female |
| Counter Balance |
None |
| Pan Handle Fittings |
2 |
| Bubble Level |
2 |
| Accessory Mounting |
1 x 1/4"-20 Female Thread |
| Base Diameter |
2.4" / 6 cm |
Pan & Tilt
| Drag Control |
None |
| Drag Type |
Friction |
| Vertical Tilt |
+90° to -75° |
| Panning Range |
360° |
| Independent Pan Lock |
Yes |
| Independent Tilt Lock |
Yes |
| Lateral Tilt |
None |
General
| Load Capacity |
22 lb / 10 kg |
| Materials |
Magnesium |
| Weight |
1.25 lb / 567 g |
Packaging Info
| Package Weight |
3.555 lb |
| Box Dimensions (LxWxH) |
15.2 x 8.4 x 4.8" |
