Description
Product Overview
The BF470 is a high-frequency PNP silicon transistor designed for applications that require high-speed switching and low noise performance. It is commonly used in RF amplifiers, switching circuits, and other high-frequency applications due to its excellent characteristics and reliable operation. The BF470 transistor is a reliable and high-performance component ideal for high-frequency and low-noise applications. Its fast switching capabilities and excellent frequency response make it a valuable choice for engineers and designers in advanced electronic systems.
- Collector-Emitter Voltage (Vceo): 50V
- Collector-Base Voltage (Vcbo): 50V
- Emitter-Base Voltage (Vebo): 5V
- Collector Current (Ic): 1A
- Base Current (Ib): 0.5A
- Power Dissipation (Pd): 1W
- DC Current Gain (hFE): 50-200 at Ic = 50mA, Vce = 10V
- Transition Frequency (ft): 1.5 GHz (typical)
- Package Type: TO-92
- Pin Configuration: 3 Pins (Collector, Base, Emitter)
- Mounting Style: Through-Hole
- Junction Temperature (Tj): -65°C to +150°C
- Thermal Resistance, Junction to Ambient (RθJA): 100°C/W
Applications
Audio, Power Supplies, DC/DC Converters, Motor Drive & Control, Signal Processing
Product details
| Transistor Polarity | PNP |
| Continuous Collector Current | 30mA |
| Transistor Case Style | TO-126 |
| No. of Pins | 3Pins |
| DC Current Gain hFE Min | 50hFE |
| Product Range | Multicomp Pro Bipolar Transistor PNP |
| MSL | - |
| Collector Emitter Voltage Max | 250V |
| Power Dissipation | 2W |
| Transistor Mounting | Through Hole |
| Transition Frequency | 60MHz |
| Operating Temperature Max | 150°C |
| Qualification | - |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | MULTICOMP PRO |
| Part Number | BF470 |
| Quantity | Each |
| Technical Data Sheet (189.89KB) EN | View or download |
