Description
Product Overview
The BD440 is a PNP silicon power transistor designed for high-current and high-power applications. It is well-regarded for its performance in switching and amplification tasks, making it suitable for use in a variety of electronic circuits including power amplifiers, motor controllers, and switching regulators. The BD440 transistor is a versatile and dependable component for high-power applications, offering solid performance and ease of integration for engineers and electronics designers.
- Collector-Emitter Voltage (Vceo): 60V
- Collector-Base Voltage (Vcbo): 60V
- Emitter-Base Voltage (Vebo): 5V
- Collector Current (Ic): 6A
- Base Current (Ib): 1A
- Power Dissipation (Pd): 40W
- DC Current Gain (hFE): 20-150 at Ic = 2A, Vce = 5V
- Package Type: TO-220
- Pin Configuration: 3 Pins (Collector, Base, Emitter)
- Mounting Style: Through-Hole
- Junction Temperature (Tj): -65°C to +150°C
- Thermal Resistance, Junction to Case (RθJC): 3.12°C/W
Applications
Audio, Power Supplies, DC/DC Converters, Motor Drive & Control, Signal Processing
Product details
| Transistor Polarity | PNP |
| Continuous Collector Current | 4A |
| Transistor Case Style | TO-126 |
| No. of Pins | 3Pins |
| DC Current Gain hFE Min | 25hFE |
| Product Range | Multicomp Pro Bipolar Transistor PNP |
| MSL | - |
| Collector Emitter Voltage Max | 60V |
| Power Dissipation | 36W |
| Transistor Mounting | Through Hole |
| Transition Frequency | 3MHz |
| Operating Temperature Max | 150°C |
| Qualification | - |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | MULTICOMP PRO |
| Part Number | BD440 |
| Quantity | Each |
| Technical Data Sheet (742.86KB) EN | View or download |
