FS36-350-C2 POWER XFMR 36 Vct @ 350 mA UL/cUL - Class 3 , TUV, 115/230V SPLIT PACK PCB MOUNT / FS36-350-C2 55X4543 New product from TRIAD MAGNETICS with the model number FS36-350-C2
Product details
| PCB Transformer Type |
Split Bobbin |
| Primary Voltages |
115V, 230V |
| Secondary Voltages |
18V |
| Power Rating |
12VA |
| Frequency Range |
50Hz / 60Hz |
| Winding Type |
Dual Primary, Dual Secondary |
| Current Rating |
350mA |
| Isolation Voltage |
4.2kVrms |
| Transformer Mounting |
Through Hole |
| Product Range |
- |
Other details
| Brand |
TRIAD MAGNETICS |
| Part Number |
FS36-350-C2 |
| Quantity |
Each |
