Description
This is a Thyristor, 1.6 kV, 150 mA, 32 A, 50 A, Module, 7 Pins product from SEMIKRON with the model number SKKT 27/16 E
Product details
| Peak Repetitive Off-State Voltage, Vdrm | 1.6kV |
| On State RMS Current IT(rms) | 50A |
| Operating Temperature Max | 125°C |
| SCR Module Type | Series Connected - SCRs |
| Gate Trigger Voltage Max Vgt | 3V |
| Product Range | - |
| Holding Current Max Ih | 200mA |
| Gate Trigger Current Max, Igt | 150mA |
| Peak Non Rep Surge Current Itsm 50Hz | 550A |
| Current It av | 32A |
Other details
| Brand | SEMIKRON |
| Part Number | SKKT 27/16 E |
| Quantity | Each |
| Technical Data Sheet EN |  |
