Description
The 733-108. is a 8-pole light grey Female Connector with coding fingers. This connector has tin-plated copper alloy contacts and a polyamide 6.6 insulator. It accepts 28 to 20AWG wire size.
- Universal connection for all conductor types
- Easy cable pre-assembly and on-unit wiring via vertical and horizontal Cage Clamp� actuation
- Strain relief plates, factory assembled or in-the-field installation
- 100% protected against mismating
- UL94V-0 Flammability rating
Applications
Industrial
Product details
| Wire Size AWG Max | 20AWG |
| Wire Connection Method | Clamp |
| Rated Current | 6A |
| No. of Positions | 8Ways |
| Conductor Area CSA | 0.5mm� |
| Product Range | 733 Series |
| Pitch Spacing | 2.5mm |
| Wire Size AWG Min | 28AWG |
| Rated Voltage | 160V |
Other details
| Brand | WAGO |
| Part Number | 733-108 |
| Quantity | Each |
| Technical Data Sheet EN |  |
