Description
Product Overview
MPS3F11-H-F-7 is a blue LED, SPST tactile switch.
- 30mA / 28VDC rating, 10mm/sec operating speed
- 25-30 operation cycles per minute operating frequency range
- 20,000 cycles electric life, 500,000 cycles mechanical life
- Force range from 3.4N to 6.4N, 10.8 ±0.2mm operating position, 2mm full travels
- POM natural pusher, POM dust protection cap
- PA nature glass fibre reinforced case, piano wire spring
- Gold plated brass contact, gold flash plated brass terminals
- Operation temperature range from -40°C to +85°C
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPS3F11-H-F-7 |
| Quantity | Each |
| Technical Data Sheet EN |  |
