Description
This is a Signal Relay, DPDT, 5 VDC, 2 A, IM Series, SMD, Non Latching product from TE CONNECTIVITY with the model number IM13GR
Product details
| Contact Configuration | DPDT |
| Coil Voltage | 5VDC |
| Contact Current | 2A |
| Product Range | IM Series |
| Relay Mounting | SMD |
| Coil Type | Non Latching |
| Contact Voltage VAC | 250V |
| Relay Terminals | Solder |
| Contact Voltage VDC | 220V |
| Contact Material | Palladium Ruthenium |
| Coil Resistance | 234ohm |
Other details
| Brand | TE CONNECTIVITY |
| Part Number | IM13GR |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
