This is a General Purpose Relay, G7L Series, Power, Non Latching, DPST-NO, 240 VAC, 25 A product from OMRON ELECTRONIC COMPONENTS with the model number G7L-2A-TUB-80-CB AC200/240
Product details
| Contact Configuration |
DPST-NO |
| Coil Voltage |
240VAC |
| Contact Current |
25A |
| Product Range |
G7L Series |
| Relay Mounting |
Panel |
| Coil Type |
Non Latching |
| Contact Voltage VAC |
277VAC |
| Relay Terminals |
Quick Connect |
| Contact Voltage VDC |
- |
| Contact Material |
Silver Alloy |
| Coil Resistance |
21kohm |
| Approvals & Standards |
CSA, IEC, UL |
Other details
| Brand |
OMRON ELECTRONIC COMPONENTS |
| Part Number |
G7L-2A-TUB-80-CB AC200/240 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
