Description
Axis Communications A1710-B Overview
Implement full control of up to four doors with the A1710-B Network Door Controller from Axis Communications. This multi-door controller is designed to control and grant access to four doors via up to eight OSDP (multidrop) or Wiegand readers and locks. Up to 250,000 credentials and 250,000 event logs can be stored locally on the A1710-B. Thanks to PoE compatibility, only a single cable is required for installation and operation. Tamper detection provides an additional layer of security.
Suitable for new and retrofit installations with Axis Communications or third-party cabinets
Axis TA1101-B Wiegand to OSDP Converter in multidrop required for Wiegand readers (available separately)
Scalable and optimized for both small and large installations
Built-in lock power management
Compact form factor
OSDP secure channel supported
Compatible with Axis Camera Station Secure Entry or partner solutions for an all-in-one video and access control management system
Built-in cybersecurity features prevents unauthorized access and safeguards your system
PVC free
Items Included
- Axis Communications A1710-B Network Door Controller
- Connector Kit (Mounted)
- Grounding Kit
- Cable Ties
- Limited 5-Year Manufacturer Warranty
Additional Resources
No additional resources available
Axis Communications A1710-B Specs
General
| Compatibility |
Various Credentials
|
| Network Protocols |
IPv4, IPv6, HTTP, HTTPS, TLS, QoS Layer 3 DiffServ, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SOCKS, SSH, MQTT v3.1.1, Syslog
|
| Languages |
English, German, French, Spanish, Italian, Russian, Simplified Chinese, Japanese, Korean, Portuguese, Polish, Traditional Chinese
|
| Memory |
512 MB RAM, 2 GB Flash
|
Inputs/Outputs
| Connectors |
Shielded 1000M RJ45 PoE
Terminal Blocks: DC Power, Inputs/Outputs, RS-485, Relay |
Power
| Power Source |
PoE
|
| DC Input Power |
12 VDC
|
| Power Consumption |
36 W
|
Physical
| Mounting |
Multiple DIN Rail, Cabinet
|
| Color |
White
|
| Material of Construction |
Steel
|
| Certifications |
CAN/CSA, CE, EN, ETSI, FCC, ICES, IEC, IEC/EN/UL, KC, RCM, RCM, REACH, RoHS, TAA, UL, VCCI, WEEE, cUL
|
| Operating Conditions |
-40 to 131°F / -40 to 55°C at 10 to 85% Humidity
|
| Storage Conditions |
-40 to 158°F / -40 to 70°C at 5 to 95% Humidity
|
| Dimensions |
8.3 x 6.5 x 1.1" / 210 x 166.1 x 28.5 mm
|
| Weight |
1.9 lb / 880 g
|
Packaging Info
| Package Weight |
2.49 lb
|
| Box Dimensions (LxWxH) |
10 x 7.7 x 2.7"
|
