Description
- Designed for Constant Use
- 1280 x 1024 Resolution at 60 Hz
- 17" LCD Backlight Display
- 160/140° Viewing Angles
- 5:4 Aspect Ratio
- 2 x 2W Built-In Speakers
- BNC/HDMI/VGA Video Inputs
- RCA Input and Audio Output
- 75 x 75mm VESA Mounting
- Wall & Ceiling Mounting / Rack-Mountable
The Economy Series 17" Rack-Mountable LCD CCTV Monitor from ORION Images supports up to 1280 x 1024 video resolution at 60 Hz for displaying high-quality surveillance footage. This commercial grade monitor is designed for always-on use, making it an ideal solution for security and law enforcement applications. There are two 2W built-in speakers for audio, and there are multiple input and output connections, including BNC, VGA, HDMI, and RCA. Additionally, the monitor is rack-mountable for placement on a shelf or in a media cabinet, and it has a 75 x 75mm VESA pattern, providing compatibility with mounting brackets for easy installation.
- Supports a maximum resolution of 1280 x 1024 at 60 Hz
- Multi-language support for ease of use and versatility
- Two BNC video inputs and one BNC output, as well as a VGA video input
- Features one HDMI input for high-definition video and audio
- One RCA audio input and two 2W built-in speakers for audio output
- Includes remote control for system navigation
- 75 x 75mm VESA mounting wall and ceiling mount compatibility
- Monitor can also be rack mounted for placement on a shelf or in a cabinet
UPC: 836228000207
In the Box
Orion Images Economy Series 17" Rack-Mountable LCD CCTV Monitor
Orion Images 17RCE specs
| Display | |
|---|---|
| Screen Size | 17.0" / 43.2 cm |
| Maximum Resolution | 1280 x 1024 at 60 Hz |
| Pixel Pitch | 0.264 x 0.264 mm |
| Brightness | 350 cd/m 2 |
| Contrast Ratio | 500:1 |
| Aspect Ratio | 5:4 |
| Viewing Angle (H/V) | 160/140° |
| Display Color | 16.2 million |
| Response Time | <6 ms |
| Video System | NTSC / PAL |
| Frequency | H: 31 to 64 kHz V: 56 to 75 kHz |
| Interface | |
|---|---|
| Video | 2 x input (BNC) 1 x output (BNC) |
| HDMI | 1 x input |
| VGA | 1 x input (15-pin D-sub) |
| Audio | 1 x input (RCA Type: left and right) 1 x output (RCA Type: left and right) |
| Transmitter | |
|---|---|
| Remote Control | Yes |
| Audio | |
|---|---|
| Built-In Speakers | 2 x 2 W |
| Features | |
|---|---|
| Filter Type | 3D comb filter |
| Languages | English, Chinese |
| Mount | |
|---|---|
| VESA Compatibility | 75 x 75 mm |
| Compatibility | Wall Mount: WB-5, WB-10, WB-30, WB-31 Ceiling Mount: CMK-01 Rack: RMK-08 |
| General | |
|---|---|
| Material | ABS plastic |
| Desktop Stand | Yes |
| Tilt Function | Yes |
| Power Consumption | <35 W 100 to 240 VAC (50/60 Hz) 12 VDC / 4 A |
| Operating Temperature | 32 to 104°F / 0 to 40°C |
| Storage Temperature | -4 to 140°F / -20 to 60°C |
| Dimensions | Without Stand: 15.0 x 12.4 x 1.7" / 38.2 x 31.5 x 4.3 cm |
| Weight | 7.4 lb (3.3 kg) |
| Package Weight | 9.45 lb |
| Box Dimensions (LxWxH) | 17.953 x 16.929 x 4.724" |
