Description
Comprehensive CDA-1248GAE Overview
Send a single HDMI input source to up to two recording and/or display destinations with the Pro AV/IT Integrator Series HDMI UHD 8K60 1x2 Distribution Amplifier/Splitter from Comprehensive. The HDMI 2.1, HDCP 2.3/2.2/1.4 compliant device supports 48 Gb/s video bandwidth with resolutions up to 8K60, and it can perform digital and analog audio extraction via its integrated SPDIF and 3.5mm audio output ports. Signal bypassing and downscaling are supported via the two HDMI outputs, along with EDID management with Copy and Auto modes.
Versatile AV Distribution
The unit distributes one HDMI source signal to two HDMI displays simultaneously at resolutions up to 8K60 1x2 and 48 Gb/s video bandwidth. It extracts audio from the HDMI source to both optical and analog outputs simultaneously, and it offers two EDID modes (Copy/Auto) with signal bypassing and video downscaling available on all HDMI outputs.
Digital & Analog Audio De-Embedding
Equipped with an optical SPDIF and a 3.5mm audio output port for de-embedding analog audio from the HDMI output, which allows connectivity to your audio amplifier or entertainment system.
Essential Functionality for Every AV Space
Ideal for use in media rooms, digital signage spaces, courtrooms, classrooms, conference rooms, places of worship, and anywhere HDMI source devices need to be distributed to multiple HDMI destinations.
UPC: 808447086706
Items Included
- Comprehensive Pro AV/IT Integrator Series HDMI UHD 8K60 1x2 Distribution Amplifier/Splitter
- 5V, 1A Power Adapter
- Limited 3-Year Manufacturer Warranty
Additional Resources
Comprehensive CDA-1248GAE Specs
Key Specs
| Inputs |
1 x HDMI (HDMI 2.1) Female
|
| Embedded Audio |
HDMI Input: 8-Channel
|
| Outputs |
2x HDMI (HDMI 2.1) Female
1x 1/8" / 3.5 mm TRS (Stereo Analog) Female 1x TOSLINK (S/PDIF) Female |
| Video Format |
HDMI (8/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV, YCC)
8K: 24/30/50/60 fps UHD 4K: 24/30/50/60/120 fps 1080p: 24/30/50/60/120/240 fps 1080i 720p: 50/60 fps 576p: 50/60 fps 576i 480p: 50/60 fps 480i |
Interfaces
| Inputs |
1 x HDMI (HDMI 2.1) Female
|
| Embedded Audio |
HDMI Input: 8-Channel
|
| Outputs |
2x HDMI (HDMI 2.1) Female
1x 1/8" / 3.5 mm TRS (Stereo Analog) Female 1x TOSLINK (S/PDIF) Female |
| Other I/O |
1x Micro-USB (Firmware) Input
|
Standards
| HDR Support |
Yes, HDR10/HDR10+/Dolby Vision/Hybrid Log Gamma
|
| HDCP Support |
Yes, Version 1.4/2.3
|
| EDID Support |
Manual Control
|
| Audio Decoding |
DSD, DTS Digital Surround, DTS-HD High-Resolution, DTS-HD Master Audio, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, LPCM, PCM
|
Transmission
| Video Format |
HDMI (8/12-Bit 4:4:4/4:2:2/4:2:0 RGB, YUV, YCC)
8K: 24/30/50/60 fps UHD 4K: 24/30/50/60/120 fps 1080p: 24/30/50/60/120/240 fps 1080i 720p: 50/60 fps 576p: 50/60 fps 576i 480p: 50/60 fps 480i |
| Audio Format |
Analog
S/PDIF |
| Audio Channels |
7.1-Channel
|
Power
| Power I/O |
1x Barrel (5 VDC at 1 A) Output
|
| Power Consumption |
(5 W)
|
| ESD Protection |
Yes
|
General
| Certifications |
CE, EU, FCC, UL
|
| Operating Conditions |
32 to 104°F / 0 to 40°C at 20 to 90% Humidity
|
| Storage Conditions |
-4 to 140°F / -20 to 60°C at 20 to 90% Humidity
|
| Material of Construction |
Metal
|
| Dimensions |
2.8 x 4.8 x 0.7" / 70.5 x 122.0 x 18.5 mm
|
| Weight |
6.6 oz / 188 g
|
Packaging Info
| Package Weight |
0.975 lb
|
| Box Dimensions (LxWxH) |
8.5 x 7.5 x 1.9"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
