Description
- Up to UHD 4K/60 YUV 4:4:4 Input/Output
- S/PDIF Optical and L/R Analog Outputs
- High Resolution Digital Audio Bypass
- 10-Bit HDR Pass-Through
- Audio Sampling Rate up to 192 kHz
- CEC Bypass
- Bit Stream Audio Switching
- HDCP 2.2 Compliant
The Comprehensive 4K HDMI Audio Extractor allows you to de-embed audio signals from up to Ultra HD 4K HDMI video sources and output them via digital optical or analog stereo L/R audio outputs. Both the HDMI input and output support up to UHD at 60/50 fps (with up to YUV 4:4:4) and 10-bit HDR pass-through. The original audio also gets passed from HDMI input through HDMI output when you de-embed. Supported audio formats include LPCM 2-channel, Dolby True HD, Dolby Digital Plus, Dolby Atmos, and DTS-HD Master Audio.
- Key Features
-
- Up to UHD 4K resolution at 60/50 fps (YUV 4:4:4) supported on input and output
- De-embed to multi-channel optical (S/PDIF) or L/R analog audio outputs
- LPCM 2-channel, Dolby Digital 2-channel/5.1-channel, and DTS 2-channel/5.1-channel support via optical audio output
- High resolution digital audio bypass
- High Bit Rate (HBR) HDMI audio pass-through
- Audio sample rates up to 192 kHz
- CEC bypass
- Bit stream audio switching
- HDMI 2.0b (18 Gb/s)
- HDCP 2.2 compliant
- DVI compliant
- RoHS certified
UPC: 808447079074
| Supported Resolution | Up to 3840 x 2160 at 60/50 fps (YUV 4:4:4) |
| Inputs | HDMI: 1 x HDMI type A |
| Outputs | HDMI: 1 x HDMI type A Stereo Analog Audio: 1 x 3.5 mm S/PDIF: 1 x optical |
| HDMI Compliance | HDMI 2.0b |
| Bandwidth | 18 Gb/s |
| Color Space | RGB, YCbCr 4:4:4, YCbCr 4:2:2 |
| Color Depth | 10-bit, 12-bit |
| HDCP Compliance | HDCP 2.2 / HDCP 1.4 |
| Audio Formats Supported | HDMI Pass-Through: LPCM 2-channel/5.1-channel/7.1-channel, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X Optical Audio: LPCM 2-channel, LPCM 5.1, Dolby Digital 2-channel/5.1-channel, DTS 2-channel/5.1-channel L/R Audio: Analog stereo 2-channel |
| Chassis | Metal |
| Power Supply | Input: 100-240 VAC, 50/60 Hz Output: 5 VDC, 1 A (US/EU standards, CE/FCC /UL certified) |
| Power Consumption | 1 W (max) |
| Operating Temperature | 32 to 104°F (0 to 40°C) |
| Storage Temperature | -4 to 140°F (-20 to 60°C) |
| Relative Humidity | 20 - 90% RH (non-condensing) |
| Dimensions | 2.9 x 2.6 x 0.7" (7.4 x 6.7 x 1.7 cm) |
| Weight | 0.3 lb (130 g) |
| Packaging Info | |
|---|---|
| Package Weight | 0.55 lb |
| Box Dimensions (LxWxH) | 4.4 x 3.4 x 2.6" |
In the Box
Comprehensive 4K HDMI Audio Extractor
- 5V/1A Power Adapter
- Limited 3-Year Warranty
