| ₹ 3785.86 includes GST and import duties. | |
| B2B customers can avail ₹ 577.34 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
BPS160-AN001B-2DH is a BPS160 series 10mm analogue pressure sensor. Typically used in medical equipment (low to medium risk), white goods, industrial P/I and process control applications.
- Improved linearity, dual horizontal port
- 4.75V minimum, 5V typical and 5.25V maximum supply voltage
- 3.2mA maximum supply current at 5V
- 13bit resolution, 2.3mS max start-up time
- Air/gas media compatibility, surface mount terminals
- Negative reference
- 14.5psi pressure
- Single vertical port
- ±1.8% FS accuracy at 20°C to 40°C, ±2.5% FS total error band, 6.5kHz sampling range
- Operating temperature range from -20°C to +100°C (-4°F to +212°F)
Product details
Other details
| Brand | BOURNS |
| Part Number | BPS160-AN001B-2DH |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 3710.14 |
| 3-5 | ₹ 3672.28 |
| 5-10 | ₹ 3596.57 |
| 10+ | ₹ 3520.85 |
Bulk discount will be automatically applied during checkout based on quantity.
