Description
The CD74HC541PWR is an inverting octal Buffer/Line Driver with 3-state outputs and the capability to drive 15 LSTTL loads. The output enables (OE1\) and (OE2\) control the 3-state outputs. If either OE1\ or OE2\ is HIGH the outputs will be in the high impedance state. For data output OE1\ and OE2\ both must be LOW.
- Buffered inputs
- Bus line driving capability
- Balanced propagation delay and transition times
- Significant power reduction compared to LSTTL logic ICs
- High noise immunity - NIL = 30%, NIH = 30% of VCC at VCC = 5V
- Typical propagation delay = 9ns at VCC = 5V, CL = 15pF, TA = 25°C
- Standard outputs - 10 LSTTL loads
- Bus driver outputs - 15 LSTTL loads
- Green product and no Sb/Br
Industrial, Automation & Process Control, Signal Processing
Other details
| Brand | TEXAS INSTRUMENTS |
| Part Number | CD74HC541PWR |
| Quantity | Each (Supplied on Cut Tape) |
| Product Change Notice EN |  |
