| ₹ 1023.34 includes GST and import duties. | |
| B2B customers can avail ₹ 156.06 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Power Relay, SPDT, 6 VDC, 16 A, RT Series, Through Hole, Latching Single Coil product from SCHRACK - TE CONNECTIVITY with the model number RT314A06
Product details
| Contact Configuration | SPDT |
| Coil Voltage | 6VDC |
| Contact Current | 16A |
| Product Range | RT Series |
| Relay Mounting | Through Hole |
| Coil Type | Latching Single Coil |
| Contact Voltage VAC | 250V |
| Relay Terminals | Solder |
| Contact Voltage VDC | - |
| Contact Material | Silver Nickel |
| Coil Resistance | 90ohm |
| Approvals & Standards | CSA, UL |
Other details
| Brand | SCHRACK - TE CONNECTIVITY |
| Part Number | RT314A06 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1002.87 |
| 3-5 | ₹ 992.64 |
| 5-10 | ₹ 972.17 |
| 10+ | ₹ 951.71 |
Bulk discount will be automatically applied during checkout based on quantity.
