Description
Aquatica 20091-KTTL-VC Overview
- 1Description
- 2Waterproofing
- 3Controls, Handling, and Operation
- 4Construction Details
- 5Lens Port System
- 6External Strobe and Light Use
- 7Mounting
Use your Canon EOS R5 mirrorless camera to capture brilliant photos and stunning video of the undersea world with the Aquatica AR5 Underwater Housing. It features a depth rating of 295', which can be upgraded to 426' for free upon request, and it is equipped with a Surveyor moisture alarm and pressure sensor. A preinstalled vacuum check system allows you to confirm watertight integrity before diving and includes a valve and pump. An Ikelite strobe connector enables the use of TTL strobe when paired with optional converter #46074, purchased from Ikelite.
The standard, coated eyepiece offers a full view of the camera's viewfinder. The housing provides access to virtually all camera functions via mechanical controls. It also has an ergonomic design with two grips that offer improved handling and attachment points for optional lighting arms. Built for durability, especially resistance to corrosion, the housing is constructed from anodized, machined aluminum and stainless steel.
The AR5 housing ships without a required lens port, though various interchangeable ports are available for different lenses.
Waterproofing
- Depth rating of 295', which is upgradeable to 426' for free upon request
- Surveyor moisture alarm (audible and visual) and vacuum sensor lets you confirm watertight integrity before the dive and alerts you in the unlikely event of a breach in waterproof seal
- Surveyor uses LED indicators
- Housing also includes vacuum valve and extracting pump, enabling you to remove excess air and create a vacuum
Controls, Handling, and Operation
- Provides easy access to virtually all camera functions via mechanical controls including push buttons, levers, and grooved dials/knobs
- Ergonomic design with two comfortable, grooved grips, which offer improved handling and attachment points for optional lighting arms
- All buttons and dials are easily accessed without having to let go of the handles
- Galileo eyepiece offers a view of the camera's viewfinder
- Optional, separately sold coated Aqua View and Aqua View 45 finders offer an enlarged, enhanced view with 100% coverage, corner-to-corner sharpness, and dioptric adjustment
Construction Details
- Precision-machined in Canada from 6061 T6 aluminum alloy, which has been anodized to MIL-A-8625 Type 2, Class 2 specifications for resistance to corrosion
- Black powder coating baked on at high temperature for extra protection
- Control shafts and push buttons made of T304 stainless steel
- Sacrificial zinc anodes protect sensitive parts of the housing bottom to prevent them from corroding
Lens Port System
- Ships without a required lens port
- Compatible with all Aquatica DSLR sized bayonet mount ports
- Supports RF mount lenses as well as EF mount, with extension ring #48474
External Strobe and Light Use
- Ikelite connector with TTL capability if used with optional converter #46074 purchased from Ikelite
Mounting
- Top 1/4"-20 accessory hole
- Dual 1/4"-20 threaded holes on top of grips for attaching optional lighting arms
- Multiple bulkhead entry/access points for connecting optional accessories, such as external monitors or remote triggering devices like pole-mounted RCS remote camera system
- Three 1/4"-20 threaded holes on the bottom for optional bracket, tray, or tripod
In the Box
- Aquatica AR5 Underwater Housing for Canon EOS R5 Mirrorless Camera (Ikelite TTL Strobe Connector, Requires Optional Converter)
- Vacuum Valve and Extracting Pump
- 2 x Ergonomic Handgrip
- Limited 1-Year Warranty
- Description
- Waterproofing
- Controls, Handling, and Operation
- Construction Details
- Lens Port System
- External Strobe and Light Use
- Mounting
Aquatica 20091-KTTL-VC Specs
| Depth Rating | 295'/ 90 m, Upgradeable to 426' / 130 m |
| Material of Construction | Housing: 6061 T6 Aluminum Alloy (MIL-A-8625 Anodized) Control Shafts and Push Buttons: T304 Stainless Steel |
| External Strobe Connector | Ikelite TTL Capable with Optional Converter #46074 |
| Moisture Alarm | Vacuum Valve, Extracting Pump, Surveyor Moisture Alarm, and Vacuum/Pressure Sensor |
| Dimensions | 9.5 x 7.1 x 6" / 24.1 x 18.0 x 15.1 cm |
| Weight | 6.5 lb / 2.9 kg |
