Description
Product Overview
ADL5375-15-EVALZ is a fully populated, 4-layer, FR4-based ADL5375 evaluation board. For normal operation, it requires a 5V/500mA power supply. The 5V power supply should be connected to the clip leads labelled VPOS and GND. The LO and baseband inputs (which should be biased at 1.5V) are applied to edge-mounted SMA-type RF connectors. The ADL5375 output drives the ADL5320 driver amplifier with its output is available at the SMA connector labelled AMP-OUT. The ADL5375's output can be accessed directly at the SMA connector labelled AMP-IN/SMA-OUT (remove R2 and install zero ohm in R1). The evaluation board also includes options to drive the LO differentially through a balun along with pads that can be used to implement a harmonic filter in the LO path.
- 400MHz to 6GHz broadband quadrature modulator (ADL5375)
