Description
Product Overview
The 502584-0260 from Molex is a CLIK-Mate 1.50mm pitch, single row, 2 circuits, vertical wire to board PCB receptacle. It mates with 502578 crimp housing.
- Tin (Sn) plated copper alloy contact
- Durability (mating cycles max) is 30
- Operating temperature range from -40°C to +105°C
- Surface mount termination
- Current rating is 2A
- Voltage rating is 100V
Applications
Automotive, Consumer Electronics, Industrial, Lighting, Medical
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
Other details
| Brand | MOLEX |
| Part Number | 502584-0260 |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
