| ₹ 148.89 includes GST and import duties. | |
| B2B customers can avail ₹ 22.71 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
The 31220104 from Metz Connect is a PT116xxVBBN (Type 220) series solderable pin header with 4 poles. The 5.08mm pitch, straight terminals plugged into the PCB and then soldered.
- Closed ends
- Codeable
- Insulating material is black colour PA66 (class CTI 600), contact pin material is CuFe
- Solder pin dimension is 1mm x 1mm, solder pin length is 3.25mm
- Recommended PC board hole diameter is 1.5mm
- Clearance and creepage distances is 4.08mm
- IP 00 protection category according to IEC 60529
- Operating temperature range from -40°C to 105°C
- Overvoltage category III, pollution degree 3, 320V rated voltage, 4KV rated test voltage
- Approved by UL, CRJUS, SEV standards
Applications
Industrial
Product details
Other details
| Brand | METZ CONNECT |
| Part Number | 31220104 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 145.91 |
| 3-5 | ₹ 144.42 |
| 5-10 | ₹ 141.45 |
| 10+ | ₹ 138.47 |
Bulk discount will be automatically applied during checkout based on quantity.
