Description
Product Overview
TLP3640A(V4TPL,E(T photorelay consists of an infrared LED optically coupled to a photo-MOSFET in a SO4 package. This photorelay has higher output current rating than phototransistor-type photocoupler. hence, it is suitable for use as On/Off control for high current. Applications include factory automation (FA), programmable logic controllers (PLCs), security systems, measuring instruments, mechanical relay replacements.
- Normally opened (1-Form-A)
- OFF-state output terminal voltage: 60V (min)
- Trigger LED current of 3mA (max)
- ON-state current of 1A (max)
- ON-state resistance of 0.3ohm (max)
- Operating temperature range from -40 to 110°C
- UL-recognized: UL 1577, File No.E67349
- cUL-recognized: CSA Component Acceptance Service No.5A File No.E67349
- VDE-approved: EN IEC 60747-5-5
- SO-4 package
Product details
Other details
| Brand | TOSHIBA |
| Part Number | TLP3640A(V4TPL,E(T |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
