Product details
Technical Specifications
Contact Form
SPST-NO (1 Form A)
MOSFET Relay Package Style
S-VSON-4
Isolation Voltage
500Vrms
Off State Leakage Current Max
1nA
SVHC
Hexahydromethylphthalic anhydride [1], Hexahydro-4-methylphthalic anhydride [2], Hexahydro-1-methylphthalic anhydride[3] (21-Jan-2025)
Relay Mounting
Surface Mount
On State Resistance Max
1.2ohm
I/O Capacitance Typ
0.6pF
Other details
Brand |
TOSHIBA |
Part Number |
TLP3431S(TP,E(O |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
 |
