Description
This is a Power Relay, SPDT, 24 VDC, 16 A, RZ Series, Through Hole, Non Latching product from SCHRACK - TE CONNECTIVITY with the model number RZ03-1C4-D024-R
Product details
| Contact Configuration | SPDT |
| Coil Voltage | 24VDC |
| Contact Current | 16A |
| Product Range | RZ Series |
| Relay Mounting | Through Hole |
| Coil Type | Non Latching |
| Contact Voltage VAC | 250V |
| Relay Terminals | Solder |
| Contact Voltage VDC | - |
| Contact Material | Silver Nickel |
| Coil Resistance | 1.44kohm |
| Approvals & Standards | UL |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | SCHRACK - TE CONNECTIVITY |
| Part Number | RZ03-1C4-D024-R |
| Quantity | Each |
| Technical Data Sheet EN |  |
