| ₹ 5833.01 includes GST and import duties. | |
| B2B customers can avail ₹ 889.53 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
G3RV-ST500-D 12VDC is a G3RV-ST series slim I/O solid state relay with integrated low profile socket. Slim I/O SSR realizes space saving due to its high-density mounting and ultra-slim body. 60% reduction in wiring time and user-friendly with a low insertion force thanks to push-in plus technology. Approved by UL (File No.E41515), TÜV (File No.R50559231, EN62314). Approved by UL (File No.E41515), TÜV (File No.R50559231, EN62314).
- 60% space saving from G3R-I/O series with 6.2mm width technology
- Maximum applicable load of 3A (DC) and 2A (AC) realized thanks to slim technology
- Output DC type has a minimum applicable load of 100µA and a leaked current of 10µA or less
- Insulation resistance of 100Mohm minimum (at 500VDC)
- Push-in plus terminal (wire connection)
- DC output (MOS FET)
- 12VDC rated voltage input, 8mA rated DC current
- 5 to 24VDC rated load voltage, 100?A to 3A (ambient temperature=25°C) load current
- IP20 degree of protection by IEC60529, operating temperature range from -30 to +55°C
Warnings
Ensure that the socket is not charged during wiring and maintenance. Not doing so may result in electric shock.
Product details
Other details
| Brand | OMRON INDUSTRIAL AUTOMATION |
| Part Number | G3RV-ST500-D 12VDC |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 5716.35 |
| 3-5 | ₹ 5658.02 |
| 5-10 | ₹ 5541.36 |
| 10+ | ₹ 5424.7 |
Bulk discount will be automatically applied during checkout based on quantity.
