OMRON INDUSTRIAL AUTOMATION G3RV-ST500-A 110VAC Solid State Relay, Ultra Slim, 2 A, 264 VAC, DIN Rail, Panel, Push In, Zero Crossing

G3RV-ST500-A 110VAC is a G3RV-ST series slim I/O solid state relay with integrated low profile socket. Slim I/O SSR realizes space saving due to its high-density mounting and ultra-slim body. 60% reduction in wiring time and user-friendly with a low insertion force thanks to push-in plus technology. Approved by UL (File No.E41515), TÜV (File No.R50559231, EN62314). Approved by UL (File No.E41515), TÜV (File No.R50559231, EN62314).

• 60% space saving from G3R-I/O series with 6.2mm width technology
• Maximum applicable load of 3A (DC) and 2A (AC) realized thanks to slim technology
• Output DC type has a minimum applicable load of 100µA and a leaked current of 10µA or less
• Insulation resistance of 100Mohm minimum (at 500VDC)
• Push-in plus terminal (wire connection)
• AC output (triac) zero cross function available
• 110VAC rated voltage input, 6.2mA rated AC current at 60Hz
• 100 to 240VAC (50/60Hz) rated load voltage, 0.1 to 2A (ambient temperature=25°C) load current
• IP20 degree of protection by IEC60529, operating temperature range from -30 to +55°C

Warnings

Ensure that the socket is not charged during wiring and maintenance. Not doing so may result in electric shock.
