Description
Product Overview
The G2RL-1A-H DC5 is a 1-pole general-purpose Power PCB Relay with DC coil, G2RL series. SPST-NO contact configuration, high sensitivity classification. 10mm/10mm clearance and creepage distance. High sensitivity with power consumption of 400mW. Offers high insulation with insulation distance above 8mm and impulse withstand voltage of 10kV between coil and contacts. Satisfies ambient operating temperature requirement of 85°C. Standard model conforms to VDE standards. Meets EN60335-1 requirements for household products.
- Flux protection enclosure
- Available in flux protection and fully sealed enclosure types
- SPST-NO, SPDT, DPST-NO, DPDT contact configurations
- UL, CSA and VDE standards approved
- Non latching coil type
- Low coil power of 400mW
- CV version available with 16A contact current, pinning 5mm, switching at 105°C
- Available in 8A, 12A and 16A switching current based on models
- Selectable coil voltage of 5VDC, 12VDC, 24VDC, 48VDC
Applications
Industrial, Power Management, Automation & Process Control, Consumer Electronics
Product details
Other details
| Brand | OMRON ELECTRONIC COMPONENTS |
| Part Number | G2RL-1A-H DC5 |
| Quantity | Each |
| Technical Data Sheet EN |  |
