Description
Product Overview
G2RL-1-E-ASI DC5 is a G2RL series, PCB power relay. It is a low-profile power relay with 15.7mm height, ideal for incorporation in miniature equipment. It is used in applications such as home appliances, OA equipment, and industrial machinery.
- 1-pole, SPDT (1c) contact form
- Flux protection (enclosure rating), high-capacity classification
- AgSnIn contact material, standard special requirement
- 5VDC rated voltage
- 80mA rated current
- 62.5 ohm coil resistance
- 12A at 250VAC, 12A at 24VDC rated load
- 440VAC, 300VDC maximum switching voltage
- Mechanical durability is 20,000,000 operations (at 18,000 operations/hr)
- Ambient operating temperature range from -40°C to 85°C (with no icing or condensation)
Product details
Other details
| Brand | OMRON ELECTRONIC COMPONENTS |
| Part Number | G2RL-1-E-ASI DC5 |
| Quantity | Each |
| Technical Data Sheet EN |  |
