| ₹ 2928.94 includes GST and import duties. | |
| B2B customers can avail ₹ 446.66 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
MPKSI480D60-L is a solid state relay. It is suitable for temperature chamber, oiler, air conditioning, lighting, fountain controller and other occasions.
- Zero crossing switching mode, LED indicator
- Dielectric strength is 4000Vrms
- Screw terminal, panel mount
- Control voltage range from 4VDC to 32VDC (DC control), 90VAC to 280VAC (AC control)
- Maximum input current is 25mA (32VDC) (DC control), 25mA (at 280VAC/50Hz) (AC control)
- Load voltage range (47 to 63Hz) is 240VAC, (48VAC to 280VAC)(Ta=25°C)
- Load current is 60A
- Minimum insulation resistance is 1000Mohm (at 500VDC)
- Ambient temperature range from -30°C to +80°C
- Maximum turn-off time is 1/2cycle+1ms (DC control), 40ms (AC control)
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPKSI480D60-L |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 2870.36 |
| 3-5 | ₹ 2841.07 |
| 5-10 | ₹ 2782.49 |
| 10+ | ₹ 2723.91 |
Bulk discount will be automatically applied during checkout based on quantity.
