Description
Product Overview
MPCMA252H-S-DC12V-BP is a PCB type miniature automotive relay. Typical applications include automatic doors and windows, central door lock, sunroof control, seat adjustment, mirror adjustment.
- SPST-NC contact Form, Ag alloy contact material
- 100mohm (6VDC 1A) maximum contact resistance, 25A motor load
- 100Mohm, 500VDC minimum insulation resistance
- 10ms maximum operate time and release time
- 1×10^5 ops ((resistance, 1s on/9s off), 1×10^5 (motor locked, 0.5s on/9.5s off) electrical life
- 12VDC nominal voltage (23°C), 160 ohm ±10% coil resistance (23°C)
- 6.5VDC operate voltage (23°C), 0.8VDC release voltage (23°C)
- 0.9W coil power (23°C)
- Dimension is 12mm ×14.5mm × 14mm
- Operating temperature range from -40°C to +85°C (standard)
Product details
Other details
| Brand | MULTICOMP PRO |
| Part Number | MPCMA252H-S-DC12V-BP |
| Quantity | Each |
| Technical Data Sheet EN |  |
