ANALOG DEVICES AD-GMSL717MIPI-EVK Evaluation Board, Serializer, GMSL2, Raspberry Pi Cameras, 15-Pin MIPI CSI-2 Ribbon Cable Interfaces

AD-GMSL717MIPI-EVK is a GMSL2 serializer board for Raspberry Pi cameras. It allows connecting a wide range of cameras with 15-pin MIPI CSI-2 ribbon cable interfaces to Analog Devices� MAX96717 GMSL2 serializer, enabling connectivity to processing systems which have GMSL2 receive interfaces. Due to its compact form-factor and mounting holes, the board can be easily and securely integrated into vision systems with various requirements in, terms of size, shape, and mobility. A detachable extension allows mounting on tripods with 1/4�-20 mounts. Open-source reference software for all supported camera types targeting a range of compute platforms such as Nvidia SoCs, Raspberry Pi, and AMD SoCs. Applications include high-resolution camera systems, autonomous guided vehicles, advanced driver assistance systems (ADAS).

• 1 x MIPI CSI (2 x lanes) 15-pin ribbon cable connector
• 4 x MFP pins routed to the ribbon cable connector
• 1 x FAKRA coaxial cable connector
• Mounting holes for easy and secure attach of all Raspberry Pi cameras form factors
• Compact form-factor, compatible with cameras having 15-pin MIPI CSI-2 ribbon cable interfaces
• Allows interfacing of a wide range of cameras
• Implements Power over Cable (PoC) eliminating the need for external power supplies
